Product Compatibility
|
Fully compatible with standards-compliant telepresence and video systems
|
|
Software Compatibility
|
Cisco TelePresence Software Version TC4.0 or later
|
|
Components
|
Fully integrated unit including:
• Codec
• Display
• Camera
• Microphone and loudspeakers
• Cables including: VGA-to-DVI-I cable, DVI-D cable, 3.5-mm jack audio cable, LAN cable, power adapter, and power cable
|
|
Display
|
• EX90
• 24-in. LCD monitor
• Resolution: 1920 x 1200 (16:9)
• Contrast ratio: 1000:1
• Viewing angle: 160°
• Response time: 5 ms
• Brightness: 300cd/m2
• 5° - 15° tilt
|
• EX60
• 21.5-in. LCD monitor (with LED backlight)
• Resolution: 1920 x 1080 (16:9)
• Contrast ratio: 1000:1
• Viewing angle: 170°
• Response time: 5 ms
• Brightness: 225cd/m2
|
|
PC and second-source video input
|
DVI-I
EX90: HDMI In.
|
|
Supported PC input resolutions
|
EX90: SVGA (800 x 600) to WUXGA (1920 x 1200)
EX60: SVGA (800 x 600) to 1080p (1920 x 1080)
|
|
Camera
|
• Cisco TelePresence PrecisionHD design
• Resolutions: 1080p30 and 720p60
• Auto focus
• Integrated privacy shutter
• Document camera mode
• Multicoated all-glass optics
• 1/3-in., 2.1 megapixel CMOS sensor
|
EX90
• Horizontal field of view: 45°-65°
• Vertical field of view: 40°-27°
• Focus distance 0.3-infinity
• Optical, motorized zoom
EX60
• Horizontal field of view: 50°
• Vertical field of view: 29°
• Focus distance 0.1-infinity
|
|
Audio system
|
• Two stereo front speakers
• Integrated full-range microphone
• One 3.5-mm line-in jack for PC or other audio source
• Two 3.5-mm jack for headset
• Wideband handset
• Bluetooth-ready
|
• Integrated subwoofer (EX90 only)
• Support for Performance Mic 20 (EX90 only)
• HDMI audio input/output (EX90 only)
|
|
User interface
|
Cisco TelePresence touch screen
• Eight-inch projected capacitive touch screen
• Resolution: 800 x 480
|
|
Language support
|
English
|
|
Physical dimensions (H x L x D)
|
Cisco TelePresence System EX90 main unit: 21.4 x 22.3 x 6.8 in. (54.5 x 56.7 x 17.3 cm)
Cisco TelePresence System EX60 main unit: 20.0 x 20.5 x 5.4 in. (50.8 x 52 x 13.8 cm)
|
• Cisco TelePresence touch screen: 1.7 x 9.0 x 5.7 in. (4.4 x 22.8 x 14.5 cm)
• Cisco TelePresence touch screen with headset: 3.0 x 11.4 x 7.4 in. (4.4 x 22.8 x 14.5 cm)
• Cable length: 47 in. (120 cm)
|
|
Weight
|
Cisco TelePresence System EX90 main unit: 24.2 lb
(11.0 kg)
Cisco TelePresence System EX60 main unit: 12.9 lb
(5.85 kg)
|
• Cisco TelePresence touch screen: 1.4 lb (0.64).
• Cisco TelePresence touch screen with handset: 2.1 lb (0.94 kg)
|
|
Power
|
Autosensing power supply
100-240 VAC, 50/60 Hz
EX90: 150 watts max EX60: 75 watts max
|
|
Temperature range
|
Operating temperature and humidity:
• Ambient temperature: 32 to 95°F (0 to 35°C)
• Relative humidity (RH): 10 to 90%
• Storage and transport temperature at RH 10-90% (noncondensing): -4 to 140°F (-20 to 60°C)
|
|
Approvals and compliance
|
• Directive 2006/95/EC (Low-Voltage Directive) - Standard EN 60950-1
• Directive 2004/108/EC (EMC Directive) - Standard EN 55022, Class A - Standard EN 55024 - Standard EN 61000-3-2/-3-3
• Approved according to UL 60950-1 and CSA 60950-1-07
• Complies with FCC15B Class A
|
