Table 1. Product Specifications
|
Specification
|
Description
|
|
Product compatibility
|
Cisco TelePresence TX1310 65:
• Cisco Unified Communications Manager 8.5.2 & 8.6.2 or later
• Cisco TelePresence Multipoint Switch 1.8 or later
• Cisco TelePresence Manager 1.8 or later
Cisco TelePresence TX1300 47:
• Cisco Unified Communications Manager 7.1.5 or later
• Cisco TelePresence Multipoint Switch 1.8 or later
• Cisco TelePresence Manager 1.8 or later
|
|
Software compatibility
|
Cisco TelePresence TX1310 65:
• Cisco TelePresence System Software Version 1.9 or later
Cisco TelePresence TX1300 47:
• Cisco TelePresence System Software Version 1.8 or later
|
|
User interface
|
• Cisco TelePresence Touch Screen (12-in.)
|
|
Cisco TelePresence high-definition camera
|
• Complementary metal oxide semiconductor (CMOS) 1/3-inch sensor
• CS-mount lens
• 1080p, 30 or 60 frames per second (fps)
• Minimum illumination: 300 lux
• Manual focus
|
|
Physical dimensions (H x W x D)
|
Cisco TelePresence TX1310 65:
• Minimum room dimensions: 8 x 16 x 12 ft (243.84 x 487.68 x 365.76 cm)
• Wall-mounted: 77.4 x 80 x 7.5 in. (196.60 x 203.20 x 19.05 cm)
Cisco TelePresence TX1300 47:
• Minimum room dimensions: 8 x 12 x 12 ft (243.84 x 365.76 x 365.76 cm)
• Free-standing version: 5.64 x 4.49 x 2.51 ft (171.91 x 136.86 x 76.51 cm)
• Tethered version: 5.64 x 4.49 x 1.44 ft (171.91 x 136.86 x 43.89 cm)
|
|
Weight
|
Cisco TelePresence TX1310 65: Maximum 600 lb (272.16 kg)
Cisco TelePresence TX1300 47: Maximum 300 lb (136.08 kg)
|
|
Power
|
Cisco TelePresence TX1310 65: Maximum 1440W, typical 1216W, standby 240W
Cisco TelePresence TX1300 47: Maximum 960W, typical 600W, standby 150W
|
|
Temperature range
|
Operating: 41 to 95ºF (5 to 35ºC)
Relative humidity: 10 to 95% (noncondensing)
|
|
Firmware upgrades
|
Downloadable from Cisco Unified Communications Manager
|
|
Regulatory compliance
|
• CE marking
• UL/CSA/IEC/EN/AS/NZS/60950
• 47CFR Part 15 Class A
• CISPR22/EN55022 Class A
|
Table 2. Video and Audio Specifications
|
Specification
|
Description
|
|
Bandwidth consumption
|
3 to 4 Mbps (1080p) or 1.5 to 3 Mbps (720p) for IP quality-of-service (QoS) connections recommended
|
|
Video standards
|
H.264, Telepresence Interoperability Protocol (TIP)
|
|
Video frame rate
|
30 fps using H.264
|
|
Data and graphics frame rate
|
• TX1300 47 and TX1310 65 graphics sharing at 5 fps (standard configuration)
• Graphics sharing at 30 fps with software license
|
|
Native National Television Standards Committee (NTSC)
|
720p and 1080p
|
|
Live video resolution
|
1920 x 1080 Native
|
|
H.264 interoperability
|
Using Common Intermediate Format (CIF), G.722, and G.711 with Cisco Unified Videoconferencing 3500 Series platforms
|
|
Audio standards
|
G.711, G.722, and AAC-LD (22 kHz)
|
|
Audio features
|
Cisco Dynamic Echo Cancellation
|
Table 3. Network, Security, and Management Specifications
|
Specification
|
Description
|
|
Protocols
|
Cisco Discovery Protocol, Session Initiation Protocol (SIP), IP, Dynamic Host Configuration Protocol (DHCP), Secure Shell (SSH) Protocol, 802.1p/q, and Real-Time Transport Protocol (RTP)
|
|
Video network features
|
Intelligent packet-loss recovery of video transmission
|
|
Network interface
|
• One LAN or Ethernet (RJ-45); 100/1000 Mbps
• Internal 4-port Ethernet switch with 2 Power over Ethernet plus (PoE+) (IEEE 802.3af) ports on codec
|
|
Other interfaces
|
Web-based user interface; IP address assignment can be statically configured or configured through the Cisco TelePresence administrator web interface
|
|
Embedded encryption
|
Support for full media and signaling encryption for up to 48 segments
|
|
Scheduling services
|
Ability to offer email calendaring and scheduling services from a web-enabled application; to take advantage of this feature, you must install and configure the Cisco TelePresence Manager server to work with your calendar and email applications
|
|
Directory services
|
Ability to offer up to 40 favorites entries for convenient speed dialing or for integration into the Cisco Unified Communications Manager general directory service, which features a search function for thousands of directory entries
|
Ordering Information
Table 4 gives ordering information for the Cisco TelePresence TX1300 Series.
Table 4. Ordering Information
|
Product Name
|
Part Number
|
|
Cisco TelePresence TX1300 471
|
CTS-1300-47
|
|
Cisco TelePresence TX1310 652
|
CTS-TX1310-65
|
|
Ordering Options for the Cisco TelePresence TX1300 Series
|
|
Power cords
|
Select the appropriate power cord pair option to plug into the wall outlets in the country where the Cisco TelePresence system will be deployed.
|
|
Presentation codec
|
CTS-HFR-COLLAB-SW (TX1300 47 & TX1310 65)
This chargeable license option enables high-frame-rate Auto Collaboration.
|
