| Item |
Description |
Part Number |
| 1 |
Cover |
| (all models) |
42C1284 |
| 2 |
Low-profile adapter |
| (all models) |
varies |
| 3 |
Riser card |
| (all models) |
42C1278 |
| 4 |
3/4-length adapter |
| (all models) |
varies |
| 5 |
SAS/SATA controller card |
| Hot-swap models (models 44x, 52x, 54x, 62x, 64x, 4Dx, 5Bx, 5Dx, 6Bx, 6Dx) |
42C1279 |
| 6 |
System board |
| (all models) |
42C1276 |
| 7 |
3.5-inch SAS/SATA hard drive backplane |
| Hot-swap models (models 44x, 52x, 62x, 4Dx, 5Bx, 6Bx) |
39M4349 |
| 8 |
SATA simple-swap hard drive back plate |
| (models 12x, 22x, 42x, 1Bx, 2Bx, 4Bx) |
39M4347 |
| 9 |
Power supply |
| 350 W (all models) |
39Y7289 |
| 10 |
2.5-inch SAS/SATA hard drive backplane |
| Hot-swap models (models 54x, 64x, 5Dx, 6Dx) |
39Y9541 |
| 11 |
2.5-inch hard drive cage |
| (models 54x, 64x, 5Dx, 6Dx) |
42C1287 |
| 12 |
2.5-inch hard drive |
| 36 GB, 10 000 rpm, hot-swap SAS (optional) |
39R7364 |
| 73 GB, 10 000 rpm, hot-swap SAS (optional) |
39R7366 |
| 13 |
2.5-inch hot-swap SAS filler panel |
| (models 54x, 64x, 5Dx, 6Dx) |
26K8680 |
| 14 |
Fan |
| 40 mm (all models) |
39M4322 |
| 15 |
3.5-inch hard drive cage |
| (models 12x, 22x, 42x, 52x, 62x, 1Bx, 2Bx, 4Bx, 4Dx, 5Bx, 6Bx) |
42C1286 |
| 16 |
Bracket ear |
| (all models) |
39M4351 |
| 17 |
3.5-inch hot-swap hard drive |
| 73 GB, 10 000 rpm, hot-swap SAS (optional) |
39R7340 |
| 146 GB, 10 000 rpm, hot-swap SAS (optional) |
39R7342 |
| 300 GB, 10 000 rpm, hot-swap SAS (optional) |
39R7344 |
| 36 GB, 15 000 rpm, hot-swap SAS (optional) |
39R7346 |
| 73 GB, 15 000 rpm, hot-swap SAS (optional) |
39R7348 |
| 146 GB, 15 000 rpm, hot-swap SAS (optional) |
39R7350 |
| 80 GB, hot-swap SATA (optional) |
39M4521 |
| 160 GB, hot-swap SATA (optional) |
39M4525 |
| 250 GB, hot-swap SATA (optional) |
39M4529 |
| 500 GB, hot-swap SATA (optional) |
39M4533 |
| 18 |
3.5-inch simple-swap hard drive |
| 80 GB, simple-swap SATA (optional) |
39M4503 |
| 160 GB, simple-swap SATA (optional) |
39M4507 |
| 250 GB, simple-swap SATA (optional) |
39M4511 |
| 500 GB, simple-swap SATA (optional) |
39M4517 |
| 19 |
3.5-inch simple-swap filler panel (SATA only) |
| (models 12x, 22x, 42x, 1Bx, 2Bx, 4Bx) |
39M4343 |
| 20 |
Front Bezel |
| (all models) |
42C1283 |
| 21 |
3.5-inch hot-swap filler panel (SAS/SATA), |
| (models 44x, 52x, 62x, 4Dx, 5Bx, 6Bx) |
39M4375 |
| 22 |
CD-ROM drive drive |
| 24X Teac Slim UltraBay Enhanced (models 12x, 22x, 42x, 44x, 52x, 54x, 62x, 64x) |
39M3559 |
| 24X HLDS Slim UltraBay Enhanced (optional) (models 12x, 22x, 42x, 44x, 52x, 54x, 62x, 64x) |
26K5427 |
| CD-RW drive |
| 24X (models 12x, 22x, 42x, 44x, 52x, 54x, 62x, 64x) |
39M3503 |
| CD-RW/DVD-ROM Combo drive |
| 24/24/8/24X HLDS Slim UltraBay Enhanced (models 1Bx, 2Bx, 4Bx, 4Dx, 5Bx, 5Dx, 6Bx, 6Dx) |
39M3541 |
| 24/24/8/24X PCC Slim UltraBay Enhanced (models 1Bx, 2Bx, 4Bx, 4Dx, 5Bx, 5Dx, 6Bx, 6Dx) |
39M3563 |
| Multi-Burner |
| 127 mm Panasonic Slim UltraBay Enhanced (optional) PCC UJ-830 |
39M3529 |
| DVD-RAM |
| (optional) |
42C0955 |
| 23 |
Operator information panel |
| (all models) |
42C1513 |
| 24 |
CD/DVD interface board |
| (all models) |
39M4354 |
| 25 |
Air baffle |
| (all models) |
39M6296 |
| 26 |
Microprocessor |
| 1.86 GHz 2M Dual core (models 42x, 44x, 4Bx, 4Dx) |
42C1141 |
| 2.13 GHz 2M Dual core (models 52x, 54x, 5Bx, 5Dx) |
42C1143 |
| 2.4 GHz 4M Dual core (models 62x, 64x, 6Bx, 6Dx) |
42C1145 |
| 2.93 GHz 256K (models 12x, 1Bx) |
42C1147 |
| 3.4 GHz 4M (models 22x, 2Bx) |
42C1274 |
| 27 |
Heat-sink retention module |
| (all models) |
39M4360 |
| 28 |
Heat-sink |
| (all models) |
39M4356 |
| 29 |
Memory |
| 512 MB PC2-5300 ECC |
41Y2725 |
| 1 GB PC2-5300 ECC |
41Y2728 |
| 2 GB PC2-5300 ECC |
41Y2731 |
| . |
Alcohol wipe |
| (all models) |
59P4739 |
| . |
Simple-swap SATA RAID backplate |
| (models 12x, 22x, 42x, 1Bx, 2Bx, 4Bx) (optional) |
42C1527 |
| . |
3.0 V battery |
| (all models) |
33F8354 |
| . |
Cables |
| Backplane, hot-swap SAS (models 44x, 52x, 62x, 4Dx, 5Bx, 6Bx) |
42C1510 |
| SAS to SATA |
42C1267 |
| Backplane, hot-swap power (models 44x, 52x, 54x, 62x, 64x, 4Dx, 5Bx, 5Dx, 6Bx, 6Dx) |
42C1509 |
| SATA (simple-swap models) (models 12x, 22x, 42x, 1Bx, 2Bx, 4Bx) |
39M6276 |
| Opterator information panel |
39M6266 |
| IDE, for CD/DVD interface card |
39M6267 |
| SAS signal, 58 cm (models 54x, 64x, 5Dx, 6Dx) |
41Y3884 |
| . |
Chassis |
| (all models) |
42C1285 |
| . |
Miscellaneous parts kit |
| (all models) |
39M4374 |
| . |
Miscellaneous parts kit 2 |
| (all models) |
39R8177 |
| . |
Tool-less 1U rail kit |
| (all models) |
24P1121 |
| . |
2-post rail kit |
| (all models) |
42C1069 |
| . |
Remote Supervisor Adapter II SlimLine |
| (all models) |
13N0833 |
| . |
CRU/FRU label |
| (all models) |
42C1281 |
| . |
Hard drive installation label |
| (all models) |
42C1282 |
| . |
System service label |
| (all models) |
42C1280 |
| . |
NetXtreme 1000 Express G Ethernet adapter |
| (all models) |
39Y6098 |
| . |
NetXtreme II 1000 Express Ethernet adapter |
| (all models) |
39Y6070 |
| . |
IBM SAS HBA Controller adapter |
| (all models) |
25R8060 |
| . |
Remote Supervisor Adapter II SlimLine |
| (all models) |
13N0833 |
| . |
Rack power cord |
| (all models) |
39M5377 |
