| Item |
Description |
Part Number |
| 1 |
Top cover |
| (all models) |
23K4219 |
| 2 |
Riser card |
| PCI-X 1.0 (all models) |
90P1957 replaces 40K8155 |
| PCI-Express x8 full-length riser card assembly (option) |
40K8161 replaces 90P1956 |
| 3 |
Heat sink |
| (all models except 0Rx, 0Sx, 0Tx, 1Rx, 1Sx, 1Tx, 2Rx, 3Rx, 3Sx, 3Tx, 4Rx, 5Rx, 5Sx, 5Tx, D1x, DAx, DRx, DSx) |
90P5281 |
| (models D1x, DAx) |
39R9058 |
| Dummy (models D1x, DAx, DRx, DSx) |
42C4027 |
| 4 |
Memory |
| 256 MB PC2-3200 DDR2 RDIMM (models 01x, 02x) |
90P1123 |
| 512 MB PC2-3200 DDR2 RDIMM (all models except 01x, 02x, D1x, DAx, DRx, DSx) |
13N1424 |
| 1 GB PC2-3200 DRR2 RDIMM (models D1x, DAx, DRx, DSx) |
73P2870 |
| 5 |
Microprocessor |
| 2.8 GHz/800 MHz (1 MB L2 cache) (models 01x, 02x) |
13N1618 |
| 2.8 GHz/800 MHz Dual Core (2 x 2 MB L2 cache) (models D1x, DAx, DRx, DSx) |
40K1643 |
| 2.8 GHz/800 MHz (2 MB L2 cache) (models 05x, 06x, 0Rx, 0Sx, 0Tx, 0Wx) |
39R7569 |
| 3.0 GHz/800 MHz (1 MB L2 cache) (model 11x) |
90P1033 |
| 3.0 GHz/800 MHz (2 MB L2 cache) (models 15x, 16x, 1Rx, 1Sx, 1Tx, 1Vx) |
13M8293 |
| 3.2 GHz/800 MHz (1 MB L2 cache) (models 21x, 22x, 2Ax) |
13N2357 |
| 3.2 GHz/800 MHz (2 MB L2 cache) (models 25x, 2Rx) |
13M8294 |
| 3.4 GHz/800 MHz (1 MB L2 cache) (model 31x) |
13N2358 |
| 3.4 GHz/800 MHz (2 MB L2 cache) (models 35x, 36x, 3Rx, 3Sx, 3Tx, 3Vx) |
13M8295 |
| 3.6 GHz/800 MHz (1 MB L2 cache) (models 41x, 42x, 4Ax) |
13N2359 |
| 3.6 GHz/800 MHz (2 MB L2 cache) (models 45x, 4Rx) |
13M8296 |
| 3.8 GHz/800 MHz (2 MB L2 cache) (models 55x, 5Rx, 5Sx, 5Tx, 5Vx) |
39R7571 |
| 6 |
Heat sink retention module |
| (all models) |
90P5282 |
| 7 |
System board |
| (all models except 0Rx, 0Sx, 0Tx, 1Rx, 1Sx, 1Tx, 2Rx, 3Rx, 3Sx, 3Tx, 4Rx, 5Rx, 5Sx, 5Tx, D1x, DAx, DRx, DSx) (Single processor only) |
32R1730 |
| (models D1x, DAx) (RoHS compliant) |
39Y6782 |
| (all models except D1x, DAx) |
39Y6958 |
| 8 |
Voltage Regulator Module (VRM) |
| 1U/75A (all models except 0Rx, 0Sx, 0Tx, 1Rx, 1Sx, 1Tx, 2Rx, 3Rx, 3Sx, 3Tx, 4Rx, 5Rx, 5Sx, 5Tx, DRx, DSx) |
24R2698 |
| 1U/75A (models D1x, DAx) |
39Y7261 |
| 9 |
Power supply |
| 585 watt (all models except 0Rx, 0Sx, 0Tx, 1Rx, 1Sx, 1Tx, 2Rx, 3Rx, 3Sx, 3Tx, 4Rx, 5Rx, 5Sx, 5Tx, DRx, DSx) |
24R2640 |
| 585 watt (all models) |
39Y7169 |
| 10 |
Chassis |
| (all models) |
90P5284 |
| 11 |
Operator information panel |
| (all models) |
23K4490 |
| 12 |
Hard drive bezel filler panel |
| (models 01x, 11x, 21x, 31x, 41x, Dx1) |
59P5236 |
| 13 |
DVD-ROM/CD-RW drive |
| 24x (primary) (models 01x, 02x, 05x, 06x, 0Wx, 15x, 16x, 21x, 22x, 25x, 31x, 35x, 36x, 41x, 42x, 45x, 5Vx, 55x, 56x, D1x) |
26K5403 |
| 24x (alternate) (models 01x, 02x, 05x, 06x, 0Wx, 15x, 16x, 21x, 22x, 25x, 31x, 35x, 36x, 41x, 42x, 45x, 5Vx, 55x, 56x, D1x) |
26K5405 |
| CD-RW/DVD drive (models 0Rx, 0Tx, 1Rx, 1Tx,1Rx, 1Tx, 2Rx, 3Rx, 3Tx, 4Rx, 5Rx, 5Tx, DRx) |
39M3545 |
| 14 |
SATA cartridge |
| (models 02x, 06x, 0Tx, 16x, 1Tx, 22x, 36x, 3Tx, 42x, 56x, 5Tx) |
23K4209 |
| 15 |
Cage assembly |
| 3.5 inch. SCSI hard drive, with CD and hard drive backplanes (models 01x, 05x, 0Rx, 11x, 15x, 1Rx, 21x, 25x, 2Rx, 31x, 35x, 3Rx, 41x, 45x, 4Rx, 55x, 5Rx, D1x, DRx) |
26K8042 |
| 2.5 inch SCSI hard drive, with hard drive backplanes (models 0Sx, 0Wx, 1Sx, 1Vx, 2Ax, 3Sx, 3Vx, 4Ax, 5Sx, 5Vx, DAx, DSx) |
23K4205 |
| 16 |
Power backplane |
| (all models) |
40K8157 |
| 17 |
Fan holder with fan backplanes |
| (all models) |
40K8156 |
| 18 |
Fan |
| 40 mm x 40 mm x 56 mm (all models) |
40K8140 |
| 19 |
Fan |
| 40 mm x 40 mm x 28 mm (all models) |
40K8139 |
| . |
Alcohol wipe |
| (all models) |
59P4739 |
| . |
3.0V battery |
| (all models) |
33F8354 |
| . |
SATA hard drive bezel filler panel |
| (models 02x, 22x, 42x) |
23K4990 |
| . |
Cable |
| 3.5 inch SCSI power (models 01x, 05x, 11x, 15x, 21x, 25x, 31x, 35x, 41x, 45x, 55x, D1x) |
23K4204 |
| 2.5 inch SCSI with power cable, signal cable, and bracket (models 05x, 0Wx, 1Vx, 2Ax, 3Vx, 4Ax, DAx) |
23K4206 |
| DVD IDE (all models except 0Sx, 0Wx, 1Sx, 1Vx, 2Ax, 3Sx, 3Vs, 3Xx, 4Ax, 5Sx, 5Sx, DAx, DSx) |
40K8152 |
| Fan power (all models) |
40K8160 |
| Front panel signal (all models except 0Rx, 0Sx, 0Tx, 1Rx, 1Sx, 1Tx, 2Rx, 3Rx, 3Sx, 3Tx, 4Rx, 5Rx, 5Sx, 5Tx, DRx, DSx) |
25R4052 |
| SCSI signal (models 01x, 05x, 11x, 15x, 21x, 25x, 31x, 35x, 41x, 45x, 55x, D1x) |
33P2353 |
| . |
Cable management arm |
| (all models) |
90P1958 |
| . |
530mm/10A cord |
| (all models) |
39M5401 |
| . |
Filler panel |
| (models 2Ax, 4Ax, DAx) |
26K8680 |
| . |
Grease |
| (all models) |
59P4740 |
| . |
Miscellaneous parts kit |
| (all models) |
90P5285 |
| |
| Bezel blank filler |
| EIA bracket assembly, left |
| EIA bracket assembly, right Rail set, DVD |
| Power supply filler |
| Screw, 3.5mm |
| Screw, M3.5 steel |
| |
| . |
Toolless rail kit |
| (all models) |
23K4218 |
| . |
Line cord |
| (all models) |
36L8886 |
| . |
PCI bracket |
| (all models) |
40K8158 |
| . |
Power cord |
| (all models) |
6952300 |
| . |
Service label |
| (all models except 0Rx, 0Sx, 0Tx, 1Rx, 1Sx, 1Tx, 2Rx, 3Rx, 3Sx, 3Tx, 4Rx, 5Rx, 5Sx, 5Tx, D1x, DAx, DRx, DSx) |
23K4220 |
| (models 0Rx, 0Sx, 0Tx, 1Rx, 1Sx, 1Tx, 2Rx, 3Rx, 3Sx, 3Tx, 4Rx, 5Rx, 5Sx, 5Tx, DRx, DSx) |
40K8138 |
| (models D1x, DAx) |
40K8137 |
| Generic (all models) |
23K4991 |
| . |
Front panel USB connector cable |
| (all models) |
40K8159 |
| . |
DVD drive bezel filler panel |
| (option) (all models) |
26K4300 |
| . |
Hard drive |
| 36 GB 10 000 rpm (option) |
39R7332 |
| 36 GB 15 000 rpm (option) |
39R7314 |
| 36.4 GB Ultra320 SCSI (option) |
90P1300 |
| 73 GB 10 000 rpm (option) |
39R7308 |
| 73 GB 10 000 rpm (option) |
39R7334 |
| 73 GB 15 000 rpm (option) |
39R7316 |
| 73.4 GB Ultra320 SCSI (option) |
90P1301 |
| 80 GB SATA (option) |
71P7293 |
| 80 GB SATA (option) |
39M4503 |
| 160 GB SATA (option) |
39M3702 |
| 250 GB SATA (option) |
39M4511 |
| 300 GB 10 000 rpm (option) |
39R7312 |
| . |
SATA hard drive tray |
| (all models) |
73P8007 |
| . |
Y cord |
| 1345 mm (all models) |
25R2567 |
