| Index |
Description |
Part Number |
| 1 |
Hard drive |
| 80 GB (type 7973, 7974 optional) |
39M4503 |
| 160 GB (type 7973, 7974 optional) |
39M4507 |
| 250 GB (type 7973, 7974 optional) |
39M4511 |
| 500 GB (type 7973, 7974 optional) |
39M4517 |
| 36 GB (type 7975, 7976 optional) |
39R7346 |
| 73 GB 10 000 rpm SAS hot-swap (type 7975, 7976 optional) |
39R7340 |
| 73 GB 15 000 rpm SAS hot-swap (type 7975, 7976 optional) |
39R7348 |
| 80 GB 7 200 rpm SATA hot-swap (type 7975, 7976 optional) |
39M4521 |
| 146 GB 10 000 rpm SAS hot-swap (type 7975, 7976 optional) |
39R7342 |
| 146 GB 15 000 rpm SAS, hot-swap (type 7975, 7976 optional) |
39R7350 |
| 160 GB 7 200 rpm SATA hot-swap (type 7975, 7976 optional) |
39M4525 |
| 250 GB 7 200 rpm SATA hot-swap (type 7975, 7976 optional) |
39M4529 |
| 300 GB 10 000 rpm SAS hot-swap (type 7975, 7976 optional) |
39R7344 |
| 500 GB SATA (type 7975, 7976 optional) |
39M4533 |
| 2 |
5.25 inch blank bezel |
| (all models) |
26K7331 |
| 3 |
3.5 inch blank bezel |
| (all models) |
39M4375 |
| 4 |
SATA hard drive |
| (optional, varies) |
. |
| 5 |
Front bezel |
| (all models) |
39Y8363 |
| 6 |
Hard drive shields |
| Fixed and rotary (type 7973, 7974) |
41Y9125 |
| 7 |
EMC shields |
| (all models) |
39Y8355 |
| 5.25 inch EMC flange, tower top 5.25 inch EMC flange, tower bottom |
| 8 |
Hard drive backplane |
| SATA (type 7973, 7974) |
41Y9078 |
| |
| Note: SATA hard drive backplane (Index 8) and Back plate with cable (Index 9) are shipped together. |
| SAS (type 7975, 7976 optional) |
39Y9757 |
| 9 |
Back plate with cable |
| (all models) |
41Y9078 |
| |
| Note: Back plate with cable (Index 9) and SATA hard drive backplane (Index 8) are shipped together. |
| 10 |
Front fan cage |
| (all models) |
41Y9067 |
| 11 |
Fan |
| 120 mm x 38 mm (all models) |
41Y9028 |
| 12 |
Microprocessor duct |
| (all models) |
39Y8501 |
| 13 |
System board with tray |
| (all models) |
42C1549 |
| (type 7975, 7976 optional) |
43W5176 |
| (type 7975, 7976 models B2x, C2x) |
43W5176 |
| 14 |
ServeRAID-8k |
| 8k adapter with battery pack (type 7975, 7976 optional) |
25R8076 |
| 3.0 V battery pack |
25R8088 |
| 15 |
VRM |
| (type 7975, 7976 models AC1, MC1, CTO) |
24R2694 |
| 16 |
Side cover with latch and bezel lock |
| (optional) |
39Y8362 |
| 17 |
Diagnostic panel kit |
| (all models) Contains: |
41Y9079 |
| |
| Blank label |
| Diagnostics label |
| Guide rail assembly |
| Power button |
| RAID enable cable |
| |
| 18 |
Blank heatsink filler |
| (type 7973, 7974) |
39M6800 |
| 19 |
Heat sink |
| (all models) |
40K7438 |
| 20 |
Microprocessor |
| Intel Xeon 5110 Dual-Core 1.6 GHz/1066 MHz (2x 2 MB L2 cache) (type 7973, 7974 model 42x) (type 7975, 7976 models 42x, 4Ax, E1G) |
41Y4275 |
| Intel Xeon E5310 Quad-Core 1.6 GHz/1066 MHz (2x 4 MB L2 cache) (type 7975, 7975 model B2x) |
43W5174 |
| Intel Xeon E5320 Quad-Core 1.86 GHz/1066 MHz (2x 4 MB L2 cache) (type 7975, 7975 model C2x) |
43W5175 |
| Intel Xeon 5120 Dual-Core 1.86 GHz/1066 MHz (2x 2 MB L2 cache) (type 7973, 7974 model 52x) (type 7975, 7976 models 52x, 5Ax, E2G) |
41Y4276 |
| Intel Xeon 5130 Dual-Core 2.0 GHz/1333 MHz (2x 2 MB L2 cache) (type 7973, 7974 models 62x, E3G) (type 7975, 7976 models 62x 6Ax, E3G) |
41Y4277 |
| Intel Xeon 5050 Dual-Core 3.0 GHz/667 MHz (2x 2 MB L2 cache) with EM64T (type 7973, 7974 model 12x) (type 7975, 7976 models 14x, 16x) |
41Y8905 |
| Intel Xeon 5140 Dual-Core 2.33 GHz/1333 MHz (2x 2 MB L2 cache) (optional) |
41Y4278 |
| Intel Xeon 5150 Dual-Core 2.66 GHz/1333 MHz (2x 2 MB L2 cache) (optional) |
41Y4279 |
| Intel Xeon 5160 Dual-Core 3.0 GHz/1333 MHz (2x 2 MB L2 cache) (optional) |
41Y4280 |
| 21 |
Microprocessor retention module |
| (all models) |
39M6783 |
| 22 |
Memory |
| 512 MB PC5300 ECC (all models) |
39M5781 |
| 1 GB PC5300 ECC (optional) |
39M5784 |
| 2 GB PC5300 ECC (optional) |
39M5790 |
| 4 GB PC5300 ECC (optional) |
39M5796 |
| 23 |
DIMM air duct |
| (all models) |
39Y8499 |
| 24 |
Power supply cage |
| (type 7975, 7976 models 16x, 4Ax, Ax, 6Ax, B2x C2x, E1G, E1G, E2G, E3G) |
24R2738 |
| 25 |
Power supply filler panel |
| (type 7975, 7976) |
24R2735 |
| 26 |
Power supply |
| 835 W (type 7975, 7976 models 16x, 4Ax, 5Ax, 6Ax, B2x, C2x, E1G, E2G, E3G) |
24R2731 |
| 27 |
Power supply |
| 670 W (type 7973, 7974 all models) (type 7975, 7976 models 14x, 42x, 52x, 62x) |
24R2720 |
| 28 |
Control panel with bracket and cables |
| (all models) |
41Y9083 |
| 29 |
USB mounting bracket for rack |
| (all models) |
41Y9068 |
| 30 |
CD-ROM drive |
| 48x (all models) |
39M3511 |
| 48x (optional) |
39M3517 |
| CD-RW/DVD-ROM Combo drive |
| 48/32/48/16X Half-High (optional) |
39M3539 |
| Half-High (optional) |
39M0135 |
| DVD-ROM drive |
| 48x (optional) |
39M3515 |
| 16/48X Half-High (optional) |
39M3569 |
| Multi-Burner |
| Half-High (optional) |
42C0951 |
| Half-High (optional) |
39M3519 |
| . |
ServeRAID 8k-l |
| (type 7975, 7976) |
25R8079 |
| . |
System board tray |
| (all models) |
41Y9077 |
| . |
Bottom cover |
| (optional) |
41Y9069 |
| . |
Side/top cover |
| (all models) |
39Y8360 |
| . |
Alcohol wipe |
| (all models) |
59P4739 |
| . |
NetXtreme 1000 adapter |
| (optional) |
39Y6081 |
| . |
NetXtreme SXG adapter |
| (optional) |
39Y6090 |
| . |
NetXtreme dual adapter |
| (optional) |
39Y6095 |
| . |
NetXtreme ECPG adapter |
| (optional) |
39Y6100 |
| . |
3.0 volt battery |
| (all models) |
33F8354 |
| . |
Bay cover |
| (all models) |
41Y9043 |
| . |
DD S/5 tape drive |
| (optional) |
40K2553 |
| . |
Blower DIMM blocker |
| (all models) |
41Y9081 |
| . |
Cables |
| Diskette drive interposer (all models) |
39R9343 |
| IDE DVD signal (all models) |
13N2466 |
| Fan harness (type 7975, 7976) - (optional) |
39Y8341 |
| Power LED (all models) |
41Y9082 |
| SAS power (type 7975, 7976) |
39Y8508 |
| Redundant rear 120x38 fans (type 7975, 7976) - (optional) |
39Y8401 |
| SAS signal (type 7975, 7976) - (optional) |
41Y9085 |
| Second serial port (all models) |
42C1053 |
| Standard hot-swap (all models) |
39Y8400 |
| Front panel USB (all models) |
26K7340 |
| . |
Chassis |
| (all models) |
41Y9084 |
| . |
Rear fan air duct |
| (all models) |
39Y8504 |
| . |
Rear fan cage |
| (all models) |
41Y9067 |
| . |
Rear fan bracket |
| (optional) |
41Y9074 |
| . |
Front stabilizer feet |
| (all models) |
26K7345 |
| . |
Filler bezel |
| (optional) |
41Y9071 |
| . |
ISC31 adapter |
| (optional) |
30R5209 |
| . |
System foot |
| (all models) |
13N2985 |
| . |
Keylock, with alike keys |
| (optional) |
26K7363 |
| . |
Keylock, with random keys |
| (optional) |
26K7364 |
| . |
Remote supervisory adapter 2 |
| (optional) |
13N0833 |
| . |
Optical Wheel Mouse |
| (all models) |
39Y9875 |
| . |
3 button USB Optical Mouse |
| (optional) |
40K9203 |
| . |
PRO/1000 GT server Ethernet adapter, DP |
| (optional) |
73P5109 |
| . |
PRO/1000 GT server Ethernet adapter, QP |
| (optional) |
73P5209 |
| . |
Rack bezel assembly |
| (optional) |
41Y9072 |
| . |
SCSI adapter |
| (optional) |
39R8750 |
| With bracket (optional) |
25R8071 |
| . |
System board I/O shield |
| (all models) |
41Y9076 |
| . |
Slide kit |
| (optional) |
41Y9070 |
| (optional) |
40K6679 |
| . |
RSA Slimline bracket |
| (optional) |
41Y9086 |
| . |
SX adapter |
| (optional) |
30R5509 |
| . |
System service label |
| (all models) |
39Y8359 |
| . |
Thermal grease |
| (all models) |
59P4740 |
| . |
Power supply interposer |
| (all models) |
39Y8356 |
