| 1 |
Top cover |
| (all models) |
43W0609 |
| 2 |
Heatsink |
| (all models) |
39Y9423 |
| 3 |
Air baffles |
| (all models) |
39Y9420 |
| 4 |
Memory |
| 512 MB PC2-5300 ECC (all except models A2x, C1x, C2x, C3x, C4x, CBx, CCx, CDx, JAx, JBx) |
39M5781 |
| 1 GB PC2-5300 ECC (models A2x, B1x, B3x, B4x, B5x, B6x, B7x, BAx, BCx, BDx, BEx, BFx, BGx, C1x, C2x, C3x, C4x, CBx, CCx, CDx, JAx, JBx, LBx, MAx) |
39M5784 |
| 2 GB PC2-5300 ECC (optional) |
39M5790 |
| 4 GB PC2-5300 ECC (optional) |
41Y2845 |
| 4 GB PC2-5300-555 ECC (optional) |
44E4402 |
| 5 |
ServeRAID |
| ServeRAID 8 with battery card (optional) |
25R8076 |
| ServeRAID 8 k-l card (all except models 46x, G6x) |
25R8079 |
| 6 |
PCI-X riser card |
| (optional) |
39Y9545 |
| 7 |
PCI Express riser card |
| (all models) |
32R2883 |
| 8 |
System board, Planar |
| SATA (modesl 22x, 32x, 42x, 46x, G6x) |
43W5900 |
| SAS (models 21x, 31x, 3Ax, 41x, 45x, 4Ax, 4Sx, 51x, 5Ax, 61x, 6Ax, 71x, 7Ax, A1x, A2x, B1x, BAx, B3x, B4x, B5x, B6x, B7x, B9x, BCx, BDx, BEx, BFx, BGx, BJx, C1x, C2x, C3x, C4x, CBx, CDx, G5x, JAx, JBx, L2x, LBx, M1x, MAx) |
44E5082 |
| SATA (model CCx) |
44E5124 |
| SAS (optional) |
44E5085 |
| 9 |
Power supply |
| AC 670 W (all models) |
39Y7189 |
| DC -48 V (optional) |
39Y7186 |
| AC 450 W (optional) |
39Y7196 |
| 10 |
Power supply filler panel |
| (all models) |
39Y9420 |
| 11 |
Chassis |
| (all models) |
39Y9522 |
| 12 |
Fan |
| Dual-fans (all models) |
26K8083 |
| 13 |
CD-RW/DVD combo drive |
| 24/24/8/24X HLDS Slim UltraBay Enhanced (all models) |
39M3541 |
| 14 |
Operator information panel |
| (all models) |
43W0625 |
| 15 |
Hot-swap filler panel |
| 2.5-inch (models 4Sx, BAx, BCx, BDx, BEx, BFx, BGx, BJx, CBx, CDx, JAx, JBx, LBx, MAx) |
26K8680 |
| 16 |
Hard drive |
| 2.5-inch hot-swap (all models) |
varies |
| 17 |
Hot-swap SAS hard drive cage |
| 2.5-inch (models 4Sx, BAx, BCx, BDx, BEx, BFx, BGx, BJx, CBx, CDx, JAx, JBx, LBx, MAx) |
32R2822 |
| 18 |
Hot-swap SAS hard disk drive backplane |
| 2.5-inch (model 4Sx) |
39Y9541 |
| 19 |
Power backplane |
| (all models) |
39Y6972 |
| 20 |
Hot-swap filler panel |
| 3.5-inch (models 45x, A1x, A2x, C1x, C2x, C3x, C4x, B1x, B3x, B4x, B5x, B6x, B7x, B9x, G5x, L2x, M1x) |
39M4375 |
| 21 |
Simple-swap filler panel |
| 3.5-inch (models 46x, G6x) |
39M4343 |
| 22 |
Hard drive |
| 3.5-inch SATA (all models) |
varies |
| 23 |
Hard drive |
| 3.5-inch SAS hot-swap (all models) |
varies |
| 24 |
Disk drive cage |
| 3.5-inch SATA Simple-swap (models 46x, CCx, G6x) |
32R2823 |
| 3.5-inch SAS hot-swap (models 45x, A1x, A2x, C1x, C2x, C3x, C4x, B1x, B3x, B4x, B5x, B6x, B7x, B9x, G5x, L2x, M1x) |
32R2821 |
| 25 |
Backplane SAS |
| 3.5-inch (models 45x, A1x, A2x, C1x, C2x, C3x, C4x, CBx, CCx, CDx, BAx, BCx, BDx, BEx, BFx, BGx, G5x, JAx, JBx, LBx, MAx) |
39M4349 |
| 26 |
SATA power cable |
| With backplate (models 46x, G6x) |
26K8060 |
| . |
Alcohol wipe |
| (all models) |
59P4739 |
| . |
3.0 V ServeRAID 8 k battery pack |
| (optional) |
25R8088 |
| . |
3.0 V battery |
| System board (all models) |
33F8354 |
| . |
Cables |
| Cable, 6 inch video (optional) |
39Y9493 |
| Cable, 6 inch serial (optional) |
39Y9495 |
| Cable, -48 V power supply (optional) |
43W0619 |
| Cable, front panel USB |
26K8058 |
| Cable, power, SAS (models 45x, 4Sx, A1x, A2x, BAx, BCx, BDx, BEx, BFx, BGx, C1x, C2x, C3x, C4x, CBx, CCx, CDx, G5x, JAx, JBx, LBx, MAx) |
26K8068 |
| Cable, signal, SAS HDD (models 45x, 4Sx, A1x, A2x, BAx, BCx, BDx, BEx, BFx, BGx, C1x, C2x, C3x, C4x, CBx, CCx, CDx, G5x, JAx, JBx, LBx, MAx) |
42C2376 |
| Rack power (all models) |
39M5377 |
| . |
Cable management arm assembly |
| 1U (all models except 45X, 46X, 4SX) |
39Y9530 |
| . |
CD-RW/DVD-ROM drive interposer card |
| (all models) |
42C3983 |
| . |
DVD filler |
| (optional) |
41Y8740 |
| . |
Hard drive |
| 1.0 TB 72000 (optional) |
43W7629 |
| 300 GB 15000 rpm hot-swap SAS (optional) |
43X0805 |
| 750 GB hot-swap SATA 7200 rpm, 3.0 GB (optional) |
43W7579 |
| 146.8 GB 10000 rpm SFF hot-swap |
43X0825 |
| 73 GB 1000 rpm SFF hot-swap SAS (optional) |
43X0839 |
| . |
3U SCSI adapter |
| (optional) |
43W4325 |
| . |
Line cord |
| 2.8M 10A (all models) |
39M5081 |
| . |
Low-profile adapter |
| (all models) |
varies |
| . |
Media bezel |
| (all models) includes front video |
39Y9507 |
| . |
Microprocessor |
| Dual-Core 1.6 GHz/1066 MHz (2 x 2 MB L2 cache) with heatsink (models 21x, 22x) |
42C4231 |
| Quad-Core 1.6 GHz/1066 MHz (8 MB L2 cache) with heatsink (model A1x) |
42D3803 |
| Quad-Core 1.0 GHz/1066 MHz (8 MB L2 cache) with heat sink (model JAx) |
42D3872 |
| Dual Core 1.86 GHz/1066 MHz (6 MB L2 cache) without heat sink (models M1x, MAx) |
44E5145 |
| Dual-Core 1.86 GHz/1066 MHz (2 x 2 MB L2 cache) with heatsink (models 31x, 32x, 3Ax) |
42C4230 |
| Quad-Core E5320 1.86 GHz/1066 MHz (8 MB L2 cache) with heatsink (model C1x) |
42D3799 |
| Quad-Core 1.86 GHz/1066 MHz (8 MB L2 cache) with heat sink (model JBx) |
43W5908 |
| Dual-Core 2.0 GHz/1333 MHz (2 x 2 MB L2 cache) with heatsink (models 41x, 42x, 4Ax) |
42C4229 |
| Dual-Core 2.33 GHz/1333 MHz (2 x 2 MB L2 cache) with heatsink (models 51x, 5Ax) |
42C4228 |
| Dual-Core 2.33 GHz with heatsink (optional) |
42D3771 |
| Dual-Core 2.66 GHz/1333 MHz (2 x 2 MB L2 cache), with heatsink (models 61x, 6Ax) |
42C4227 |
| Dual-Core 3.0 GHz/1333 MHz (2 x 2 MB L2 cache) with heatsink (models 71x, 7Ax) |
42C4226 |
| Quad-Core 3.0 GHz/1333 MHz (8 MB L2 cache) with heat sink (models C4x, CDx) |
44E5039 |
| Dual-Core 3.0 GHz/667 MHz (2 x 2 MB L2 cache) with heatsink (models G5x, G6x) |
42C4001 |
| Dual-Core3.73 GHz/1067 MHz (2 x 2 MB L2 cache) with heatsink (models 45x, 46x, 4Sx) |
42C3998 |
| Quad-Core E5335 2.0 GHz/1333 MHz (8 MB L2 cache) with heatsink (model A2x) |
42D3801 |
| Quad-Core E5345 2.33 GHz/1333 MHz (8 MB L2 cache) with heatsink (models C2x, CBx) |
42D3800 |
| Quad-Core X5355 2.66 GHz/1333 MHz (8 MB L2 cache) with heatsink (models CCx, C3x) |
42D3802 |
| Quad-Core 2.00 GHz/1333 MHz (12 MB L2 cache) 80W, without heat sink (models BAx, B1x) |
44R5644 |
| Quad-Core 2.50 GHz/1333 MHz (12 MB L2 cache) 80W, without heat sink (models BCx, B3x) |
44R5646 |
| Quad-Core 2.50 GHz/1333 MHz (12MB L2 cache) 50W, without heat sink (models L2x LBx) |
44E5144 |
| Quad-Core 2.66 GHz/1333 MHz (12 MB L2 cache) 80W, without heat sink (models BDx, B4x) |
44R5647 |
| Quad-Core 2.83 GHz/1333 MHz (12 MB L2 cache) 80W, without heat sink (models BEx, B5x) |
44R5648 |
| Quad-Core 3.0 GHz/1333 MHz (12 MB L2 cache) 80W, without heat sink (models BFx, B6x) |
44R5649 |
| Quad-Core 3.16 GHz/1333 MHz (12 MB L2 cache) 120W, without heat sink (models BGx, B7x) |
44E5066 |
| Quad-Core 3.00 GHz/1333 MHz (12 MB L2 cache) 120W, without heat sink (models B9x, BJx) |
44E5117 |
| Quad-Core 2.33 GHz/1333 MHz (12 MB L2 cache) 80W, without heat sink (optional) |
44R5645 |
| . |
Miscellaneous parts kit |
| (all models) |
26K8080 |
| . |
Optical interposer card |
| (all models) |
42C3983 |
| . |
QLogic iSCSI single-port PCIe adapter |
| (optional) |
39Y6148 |
| . |
QLogic iSCSI dual-port PCIe adapter |
| (optional) |
42C1772 |
| . |
Server adapter |
| PRO/1000 PF (optional) |
42C1752 |
| PRO/1000 PT quad port server adapter (optional) |
39Y6138 |
| 10 GB PCIe SR (optional) |
42C1762 |
| . |
Service label |
| (models 45x, 4Sx, A1x, A2x, BAx, BCx, BDx, BEx, BFx, BGx, C1x, C2x, C3x, C4x, CBx, CCx, CDx, G5x, JAx, JBx, LBx, MAx) |
43W0610 |
| 3.5-inch SATA (models 46x, G6x) |
32R2820 |
| CRU/FRU (all models) |
43V4869 |
| Right fan door (all models) |
39Y9418 |
| . |
Slide kit |
| (all models except 45x, 46x, 4Sx) |
39Y9510 |
| . |
Thermal grease kit |
| (all models) |
41Y9292 |
| . |
Toolless rail kit |
| models (45X, 4SX, 46X) |
43V5369 |
| . |
Y jumper cord |
| (optional) |
39M5450 |
