Cover |
| (all models) |
59Y3790 |
| 2 |
PCI Express riser card |
| x8 (all models) |
69Y4324 |
| x8 for Emulex 10 Gigabit Ethernet (all models) |
59Y3818 |
| x16 (all models) |
69Y4325 |
| 3 |
PCI-X riser card |
| (all models) |
69Y4326 |
| 4 |
Heat sink |
| 95 W processor (all models) |
49Y4820 |
| 130 W processor (all models) |
69Y1207 |
| 5 |
Microprocessor |
| Quad-Core Intel Xeon X5570 2.93 GHz (8 MB L2 cache) 95 W (all models) |
46D1262 |
| Quad-Core Intel Xeon X5560 2.8 GHz (8 MB L2 cache) 95 W (all models) |
46D1263 |
| Quad-Core Intel Xeon X5550 2.66 GHz (8 MB L2 cache) 95 W (all models) |
46D1264 |
| Quad-Core Intel Xeon E5540 2.53 GHz (8 MB L2 cache) 80 W (all models) |
46D1265 |
| Quad-Core Intel Xeon E5530 2.4 GHz (8 MB L2 cache) 80 W (all models) |
46D1266 |
| Quad-Core Intel Xeon E5520 2.26 GHz (8 MB L2 cache) 80 W (all models) |
46D1267 |
| Quad-Core Intel Xeon E5506 2.13 GHz (4 MB L2 cache) 80 W (model A2x) |
46D1270 |
| Quad-Core Intel Xeon E5504 2.0 GHz (4 MB L2 cache) 80 W (all models) |
46D1271 |
| Quad-Core Intel Xeon X5667 3.06 GHz (12 MB cache) 95 W (all models) |
49Y7050 |
| Hexa-Core Intel Xeon X5670 2.93 GHz (12 MB cache) 95 W (model M2x) |
49Y7038 |
| Hexa-Core Intel Xeon X5660 2.8 GHz (12 MB cache) 95 W (model L2x and L4x) |
49Y7039 |
| Hexa-Core Intel Xeon X5650 2.66 GHz (12 MB cache) 95 W (models J2x, JSx, and D4x) |
49Y7040 |
| Quad-Core Intel Xeon E5640 2.66 GHz (12 MB cache) 80 W (model G2x) |
49Y7051 |
| Quad-Core Intel Xeon E5630 2.53 GHz (12 MB cache) 80 W (model F2x) |
49Y7052 |
| Quad-Core Intel Xeon E5620 2.4 GHz (12 MB cache) 80 W (model D2x) |
49Y7053 |
| Hex-Core Intel Xeon L5640 2.26 GHz (12 MB cache) 60 W (models H2x and H4x) |
49Y7054 |
| Quad-Core Intel Xeon E5507 2.26 GHz (4 MB cache) 80 W (model B2x) |
69Y0782 |
| Quad-Core Intel Xeon L5630 2.13 GHz (12 MB cache) 40 W (model C2x) |
59Y3691 |
| Dual-Core Intel Xeon E5503 2.0 GHz (4 MB cache) 80 W (all models) |
69Y0781 |
| Quad-Core Intel Xeon L5609 1.86 GHz (12 MB cache) 40 W |
69Y0783 |
| Six-Core Intel Xeon X5680 3.33 GHz (12 MB cache) 130 W (model N2x) |
69Y0849 |
| Quad-Core Intel Xeon X5677 3.46 GHz (12 MB cache) 130 W (all models) |
69Y0850 |
| Hexa-Core Intel Xeon E5645 2.4 GHz (12 MB cache) 80 W (all models) |
69Y4714 |
| Quad-Core Intel Xeon E5603 1.6 GHz (4 MB cache) 80 W (all models) |
81Y5952 |
| Quad-Core Intel Xeon E5606 2.13 GHz (8 MB cache) 80 W (all models) |
81Y5953 |
| Quad-Core Intel Xeon E5607 2.26 GHz (8 MB cache) 80 W (all models) |
81Y5954 |
| Hexa-Core Intel Xeon E5649 2.53 GHz (12 MB cache) 80 W (all models) |
81Y5955 |
| Quad-Core Intel Xeon X5647 2.93 GHz (12 MB cache) 130 W (all models) |
81Y5956 |
| Quad-Core Intel Xeon X5672 3.2 GHz (12 MB cache) 95 W (all models) |
81Y5957 |
| Hexa-Core Intel Xeon X5675 3.06 GHz (12 MB cache) 95 W (model 72x) |
81Y5958 |
| Quad-Core Intel Xeon X5687 3.6 GHz (12 MB cache) 130 W (all models) |
81Y5959 |
| Hexa-Core Intel Xeon X5690 3.46 GHz (12 MB cache) 130 W (model 72x) |
81Y5960 |
| 6 |
Microprocessor retention module |
| (all models) |
49Y4822 |
| 7 |
Battery |
| 3.0 Volt (all models) |
33F8354 |
| 8 |
Virtual media key |
| (optional) |
46C7528 |
| 9 |
Ethernet adapter |
| (optional) |
69Y4509 |
| 10 |
System board |
| (all models) |
81Y6625 |
| P12 |
69Y5082 |
| 11 |
Memory |
| 1 GB (Single-Rank x8) 1.5 V DDR3-1333 RDIMM (all models) |
49Y1442 |
| 2 GB (Dual-Rank) 1.5 V DDR3-1333 RDIMM (all models) |
49Y1443 |
| 2 GB (Single-Rank) DDR3-1333 RDIMM (all models) |
49Y1444 |
| 4 GB (Dual-Rank x4) DDR3-1333 RDIMM (models A2x, B2x, D2x, G2x, F2x, J2x,L2x, M2x, N2x, JSx) |
49Y1445 |
| 8 GB (Dual-Rank x8) DDR3-1333 RDIMM (all models) |
49Y1446 |
| 2 GB (Dual-Rank x8) PC3-10600R-999 DDR3 ECC DIMM (all models) |
44T1573 |
| 2 GB (Single-Rank x8) PC3-10600R-999 DDR3 ECC DIMM (all models) |
44T1582 |
| 4 GB (2 Gb 2Rx8) 2GBIT RDIMM |
44T1598 |
| 2 GB (Dual-Rank x8) 1333 MHz LP UDIMM (all models) |
49Y1410 |
| 16 GB (Dual-Rank x4) DDR3-1333 MHz LP RDIMM |
49Y1565 |
| 16 GB (Quad-Rank x4) 1333 MHz LP RDIMM (all models) |
46C7489 |
| 4 GB ( Dual-Rank x8) 1.35 V ECC RDIMM |
49Y1412 |
| 8 GB (Dual-Rank x4) 1333 MHz LP RDIMM (all models) |
49Y1415 |
| 8 GB (Dual-Rank x4) 1333 MHz LP RDIMM (all models) |
49Y1416 |
| 16 GB (Quad-Rank x4) 1333 MHz LP RDIMM (all models) |
49Y1418 |
| 2 GB (Single-Rank x8) PC3-10600R-999 DDR3 ECC DIMM (all models) |
49Y1421 |
| 4 GB ( Dual-Rank x8) 1333 MHz LP UDIMM (all models) |
49Y1422 |
| 2 GB (Single-Rank x8) 1333 MHz LP RDIMM (all models) |
49Y1423 |
| 4 GB (Single-Rank x4) 1333 MHz LP RDIMM (all models) |
49Y1424 |
| 4 GB (Dual-Rank x8) 1333 MHz LP RDIMM (all models) |
49Y1425 |
| 12 |
Power supply |
| 675 W, High Efficiency (all models) |
39Y7218 |
| 675 W, AC (all models) |
39Y7225 |
| 675 W, AC (all models) |
39Y7227 |
| 460 W, AC (all models) |
39Y7229 |
| 460 W, AC (all models) |
39Y7231 |
| 675 W, AC (all models) |
39Y7236 |
| 675 W, DC (all models) |
39Y7215 |
| 13 |
Power-supply bay filler |
| (all models except F2x and JSx) |
49Y4821 |
| 14 |
Optical drive |
| DVD-ROM drive (all models) |
44W3254 |
| DVD-RW drive (model JSx) |
44W3256 |
| 15 |
Operator information panel |
| (all models) |
44E4372 |
| 16A |
4-drive filler panel |
| Hot-Swap (all models) |
49Y5359 |
| Simple-Swap (all models) |
49Y5360 |
| 16B |
Hot-Swap hard drive filler |
| (models A2x, B2x, C2x, D2x, F2x, G2x, H2x, J2x, L2x, M2x, and N2x) |
44T2248 |
| 17 |
Rack latch kit |
| (all models) contains: |
49Y5356 |
| Bracket, EIA left assembly (1) |
| Bracket, EIA right assembly (1) |
| Screw, M 3.5 steel (2) |
| 18 |
Bezel |
| 16 hard drive (all models) |
59Y3780 |
| 19A |
SAS Backplane |
| 4 hard drives (all models) |
43V7070 |
| 19B |
SAS Backplane |
| 8 hard drives (all models) |
69Y0650 |
| 8 hard drives (all models) |
94Y6670 |
| 20 |
Remote RAID battery tray |
| (all models) |
49Y5355 |
| 21 |
ServeRAID |
| ServeRAID BR10i (all models) |
44E8690 |
| ServeRAID MR10i (all models) |
43W4297 |
| 22 |
flash device |
| 2 GB Hypervisor flash device (all models) |
42D0545 |
| 4 GB Hypervisor flash device (field use only) |
41Y8279 |
| 23 |
SAS riser card |
| (non-tape models) |
43V7067 |
| 24 |
240 VA safety cover |
| (all models) |
49Y4823 |
| 25 |
Fan cage |
| (all models) |
49Y5362 |
| 26 |
Fans |
| Hot-Swap dual 60 mm |
49Y5361 |
| 27A |
DIMM air baffle |
| (included in air baffle kit) (all models) |
59Y3779 |
| 27B |
Microprocessor air baffle |
| (included in air baffle kit) (all models) |
59Y3779 |
| 28 |
Tape kit |
| (optional) contains: |
40K6449 |
| Assembly, mechanical (1) |
| Clamp, round cable (1) |
| Filler, tape kit 3.5 inch (1) |
| Screws, M3x6 MPC (4) |
| 29 |
Bezel |
| 8 hard drive with tape drive (all models) |
59Y3781 |
| 30 |
Tape enabled SAS riser card |
| (optional) |
43V7065 |
| . |
Hard drive |
| 146 GB 10 000 rpm Hot-Swap SAS hard drive (all models) |
42D0633 |
| 73 GB 15 000 rpm Hot-Swap SAS hard drive (optional) |
42D0673 |
| 146 GB 15 000 rpm 2.5-inch Hot-Swap SAS hard drive (all models) |
42D0678 |
| 300 GB 10 000 rpm 2.5-inch Hot-Swap SAS hard drive (all models) |
42D0638 |
| 500 GB 10 000 rpm 2.5-inch Hot-Swap SAS hard drive (all models) |
42D0708 |
| 300 GB 10 000 rpm 2.5-inch Slim Hot-swap SAS hard drive (all models) |
44W2265 |
| 146 GB 15 000 rpm 2.5-inch Slim Hot-swap SAS hard drive (all models) |
44W2295 |
| 500 GB 7 200 SFF SAS SAP hard drive (all models) |
49Y1892 |
| 600 GB 10 000 SAS Slim Hot-swap hard drive (all models) |
49Y2004 |
| 500 GB 7 200 rpm SATA hard drive (all models) |
81Y9727 |
| . |
SAS expander card |
| for 16 hard drives (all models) |
46M0997 |
| . |
DVD Blank Filler |
| (all models except JSx) |
49Y4868 |
| . |
Emulex 10 Gigabit Ethernet custom adapter |
| (all models) Requires riser card FRU 59Y3818 |
49Y4202 |
| |
Ethernet adapter |
| NetXtreme II 1000 Express Quad-Port |
49Y4222 |
| . |
QLogic 10 Gigabit Dual-Port CN |
| (all models) |
42C1802 |
| . |
QLogic 10 Gigabit SFP+SR |
| (all models) |
42C1816 |
| |
Brocade 10 Gigabit SFP+ SR optical transceiver |
| (all models) |
42C1819 |
| |
Brocade 10 Gigabit CNA |
| for IBM System x (all models) |
42C1822 |
| . |
ServeRAID |
| ServeRAID-BR10il (model A2x) |
49Y4737 |
| ServeRAID-M5014 (models F2x and G2x) |
46M0918 |
| ServeRAID-M5015 (models J2x, JSx, L2x, and M2x) |
46M0851 |
| ServeRAID-B5015 SAS/SATA (all models) |
46M0970 |
| ServeRAID-M1015 (models B2x, C2x, D2x, H2x, and N2x) |
46M0861 |
| . |
ServeRAID M5000 series advanced feature key |
| (all models) |
46M0931 |
| . |
ServeRAID M1000 series advanced feature key |
| (all models) |
46M0864 |
| . |
IBM 3 Gigabit SAS HBA v2 |
| (all models) |
44E8701 |
| . |
Carrier daughter card |
| (all models) |
44E8763 |
| |
Daughter card mechanic kit |
| 1 GB |
69Y4586 |
| . |
Miscellaneous parts kit |
| (all models) contains: |
69Y4505 |
| Bracket, DVD retention (1) |
| Bracket, PCI fill blank (1) |
| Bracket, tooless filler (1) |
| Gasket, EMC 112mm (2) |
| Guide, PCI card (1) |
| Latch, 2U SAS controller (1) |
| Latch, expander clip (1) |
| Latch, PCI card (1) |
| Screw, 10x32 shoulder (3) |
| Screw, M3 x 0.5 L5 (10) |
| Screw, M 3.5 steel (10) |
| Screw, M6 hex head (3) |
| Screw, slotted M3X5 (10) |
| Standoff, shaft (2) |
| . |
Enterprise slide rail kit |
| (all models) |
69Y5085 |
| |
Gen-II Slide rail kit |
| (all models) |
69Y4391 |
| |
Gen-II CMA kit |
| (all models) |
69Y4392 |
| |
CMA kit |
|
| (all models) |
59Y4822 |
| . |
Universal slide rail kit |
| (all models) |
59Y3792 |
| . |
Cable management arm |
| (all models) |
49Y4817 |
| . |
Cables |
| Simple-Swap |
59Y3782 |
| Backplane configuration for 8 drives (all models) |
69Y0648 |
| Backplane configuration for 4 drives (all models) |
69Y4233 |
| Backplane configuration for 8 drives with tape (all models) |
69Y4228 |
| Backplane power cable for 4 drives (all models) |
69Y4234 |
| Backplane power cable for 8 drives (all models) |
69Y0649 |
| SAS signal (300 mm) (all models) |
49Y5390 |
| SAS signal (240 mm) (all models) |
49Y5392 |
| SAS signal (450 mm) (all models) |
59Y3921 |
| Operator information panel (all models) |
46C4139 |
| SAS signal (245 mm) (all models) |
59Y3786 |
| SAS signal (250 mm) (all models) |
69Y1332 |
| SAS signal (300 mm) (all models) |
49Y5390 |
| SAS signal (710 mm) (all models) |
69Y1328 |
| SATA DVD (all models) |
43V6914 |
| USB/video (all models) |
46C4146 |
| VGA power (all models) |
59Y3455 |
| USB power (all models) |
39M6797 |
| |
Line cord |
| 2.8 meter (all models) |
39M5377 |
| |
CPU extraction tool |
| (all models) |
81Y9398 |
| . |
Alcohol wipes |
| (all models) |
59P4739 |
| . |
Thermal grease kit |
| (all models) |
41Y9292 |
| . |
System service label |
| (all models) |
59Y3789 |
| . |
Chassis label |
| (all models) |
59Y3788 |
| |
LP latch |
| (all models) |
69Y5119 |
| . |
8 GB HBA adapter |
| (all models) |
42D0516 |
| . |
Mechanical chassis |
| (all models) |
81Y6842 |
| . |
Video |
| NVIDIA FX 3800 (all models) |
43V5894 |
| NVIDIA FX 1800 (all models) |
43V5886 |
| NVIDIA FX 1700 (all models) |
43V5765 |
| NVIDIA FX 580 (all models) |
43V5890 |
| NVIDIA FX 570 (all models) |
43V5782 |
| . |
DVI-A Dongle adapter |
| (all models) |
25R9043 |
| . |
ServeRAID MR10M battery carrier |
| (all models) |
44E8844 |
| |
Screw kit |
|
| (all models) |
59Y4922 |
Купить / Заказать / Узнать цену
