| 2 |
Top cover |
| (All models) |
69Y2296 |
| 3 |
PCI Express Gen2 riser card assembly |
| x16 full-length |
69Y2330 |
| x16 half-length |
69Y2329 |
| x8 two-slot (all models) |
69Y2328 |
| 4 |
Heat sink assembly |
| (all models) |
49Y9936 |
| 5 |
Microprocessor |
| Quad-Core Xeon E6510 1.73 GHz 105 W |
49Y9932 |
| Quad-Core Xeon E7520 1.86 GHz 95 W |
49Y9931 |
| Six-Core Xeon E7-4807 1.86 GHz 18M 95 W |
88Y5696 |
| Six-Core Xeon L7545 1.86 GHz 95 W |
49Y9928 |
| Six-Core Xeon E7530 1.86 GHz 105 W |
49Y9930 |
| Six-Core Xeon E7540 2.00 GHz 105 W |
49Y9929 |
| Six-Core Xeon E6540 2.00 GHz 105 W |
49Y9934 |
| Six-Core Xeon X7542 2.67 GHz 130 W |
49Y9935 |
| Six-Core Xeon E7-2803 1.73 GHz 18M 105 W (models A1x, A1X) |
88Y5701 |
| Eight-Core Xeon L7555 1.86 GHz 95 W |
49Y9926 |
| Eight-Core Xeon X7550 2.00 GHz 130 W |
49Y9927 |
| Eight-Core Xeon X6550 2.00 GHz 130 W |
49Y9933 |
| Eight-Core Xeon E7-2820 2.00 GHz 18M 105 W (model A2x) |
88Y5700 |
| Eight-Core Xeon X7560 2.27 GHz 130 W |
49Y9925 |
| Eight-Core Xeon E7-8837 2.67 GHz 24M 130 W (model C1x) |
88Y5691 |
| Eight-Core Xeon E7-2830 2.13 GHz 24M 105 W (model A3x) |
88Y5699 |
| Ten-Core Xeon E7-2850 2.00 GHz 24M 130 W (model A5x) |
88Y5731 |
| Ten-Core Xeon E7-8867 2.13 GHz 30M 105 W |
88Y5688 |
| Ten-Core Xeon E7-2860 2.26 GHz 24M 130 W (models A6x, d1x, D2x, F1x, F2x) |
88Y5698 |
| Ten-Core Xeon E7-2870 2.40 GHz 30M 130 W (models A7x, H1x, H2x, H3x, H7Y) |
88Y5697 |
| 6 |
Air baffle |
| Microprocessor (this part is included in part number 69Y2300) (all models) |
(69Y2300) |
| 7 |
System board |
|
| Intel 7500 scalable memory buffer |
49Y9497 |
| Use in Machine Types 7148 and 7149 only |
| Intel 7510 scalable memory buffer |
81Y8964 |
| Use in Machine Types 7147 and 7192 only |
| (models A1xx, A2x, A3x, A5x, A6x, A7x, C1x, D1x, D2x, F1x, F2x, H1x, H2, H3x, A1X, H7Y) |
| 8 |
Fan |
| Hot-Swap 60 mm (all models) |
69Y2273 |
| 9 |
Fan cage assembly |
| (all models) |
69Y2297 |
| 10 |
Bracket assembly |
| Top cover or power cut-off switch (all models) |
69Y2284 |
| 11 |
Chassis assembly |
| (without front bezel) - (all models) |
69Y2298 |
| 12 |
Bezel |
| (all models) |
69Y2293 |
| 13 |
Operator information panel assembly |
| (all models) |
44E4372 |
| 14 |
DVD-ROM drive |
| (all models) |
44W3256 |
| 15 |
Filler |
| 4x4 Hot-Swap drive bay |
49Y5359 |
| 15 |
Hard drive |
| 73 GB 15000 rpm 2.5-inch SAS Hot-Swap |
42D0673 |
| 16 |
Hard drive |
| 146 GB 10000 rpm 2.5-inch SAS Hot-Swap |
42D0633 |
| 146 GB 15000 rpm 2.5-inch SAS Hot-Swap |
42D0678 |
| 300 GB 10000 rpm 2.5-inch SAS Hot-Swap |
42D0638 |
| 500 GB 7200 rpm 2.5-inch SAS Hot-Swap |
42D0708 |
| 50 GB 2.5-inch SAS Solid State drive Hot-Swap |
43W7717 |
| 17 |
Filler |
| Single drive bay (2.5-inch drive) (all models) |
44T2248 |
| 18 |
Solid state drive |
| 50 GB 1.8-inch SAS Hot-Swap |
43W7737 |
| 19 |
Backplane cage assembly |
| 8x1.8-inch SAS or SATA Hot-Swap |
59Y6222 |
| (model 3Dx, 3Fx, 3Jx, D1x, D2x, H1x, H2x, H3x, H7Y) |
| 20 |
Hard drive |
| 2.5-inch Simple-Swap SATA 500 GB |
43W7689 |
| 21 |
Backplate or cable assembly |
| Single Simple-Swap SATA |
69Y2282 |
| 22 |
Filler |
| 4x4 drive backplane (all models) |
69Y2286 |
| 23 |
Backplane |
| 4x2.5-inch SAS or SATA Hot-Swap drive |
43V7070 |
| (models 1Rx, 2Rx, 3Gx, 3Rx, 4Rx, 3Sx,, 4Sx, 2Dx, 4RX, A2x, A3x, A5x, A6x, A7x, C1x, F1x, F2x) |
| 24 |
Backplane |
| 8 x 2.5-inch SAS or SATA Hot-Swap drive |
69Y0650 |
| 25 |
Power interposer card |
| (models 2Cx, 2Dx, 3Dx, 3Jx, D1x, D2x, F1x, F2x, H1x, H2x, H3x, H7Y) |
49Y9480 |
| 26 |
Power supply |
| 675 W (all models) |
39Y7218 |
| 27 |
DIMM air baffle |
| DIMM air baffle |
69Y2291 |
| 28 |
Memory |
| 2 GB DDR3 1333 MHz ECC LP RDIMM |
49Y1443 |
| 2 GB PC3-10600R-999 DDR3 ECC (model 4Rx) |
44T1491 |
| 4 GB PC3-10600R-999 DDR3 ECC (models 1Rx, 2Rx, 3Rx, 3Gx, 4Rx, and ARx, F1x, F2x) |
44T1598 |
| 4 GB (1.35V) PC3L-10600R-999 CL9 DDR3 ECC |
49Y1425 |
| (models A1x, A2x, A3x, A5x, A6x, A7x, C1x, D1x, D2x, F1x, F2x, A1X) |
| 4 GB PC3-12800 DDR3 |
49Y1561 |
| 4 GB PC3-8500-777 DDR3 ECC |
46C7452 |
| 8 GB PC3-8500-777 DDR3 ECC |
46C7488 |
| 8 GB (1.35V) PC3L-8500R-777 CL7 DDR3 ECC |
49Y1417 |
| 16 GB (1.35V) PC3-10600 DDR3 ECC |
49Y1564 |
| 16 GB (1.35V) PC3-10600 DDR3 ECC |
49Y1568 |
| 16 GB (1.35V) PC3L-10600 LP DDR3 ECC (7147, 7192) |
49Y1563 |
| 16 GB PC3-8500-777 DDR3 ECC |
46C7489 |
| 16 GB (1.35V) PC3L-8500R-777 CL7 DDR3 ECC (models H1x, H2x, H3x, H7Y) |
49Y1418 |
| 32 GB (1.35V) PC3L-8500R-777 CL7 DDR3 ECC |
90Y3101 |
| 29 |
Memory tray |
| (with no memory board) - (models 2Cx, 2Dx, 3Dx, 3Fx, 3Jx, F1x, F2x) |
69Y2274 |
| 30 |
RAID battery tray |
| (this part is included in part number 69Y2300) |
(69Y2300) |
| 31 |
PCI Express Gen2 riser card assembly |
| x8 low-profile |
49Y6576 |
| (models A2x, A3x, A5x, A6x, A7x, C1x, D1x, D2x, F1x, F2x, H1x, H2x, H3x, H7Y) |
| 32 |
SAS cable guide |
| (this part is included in part number 69Y2300) |
(69Y2300) |
| . |
Tray |
| RAID battery or flash power module |
88Y5874 |
| . |
Memory tray and board assembly |
| (machine types 7148 and 7149) |
49Y6531 |
| (machine types 7147 and 7192) (models F1x, F2x, H1x, H2x, H3x, H7Y) |
81Y8956 |
| . |
Emulex 10 Gb Ethernet Custom Adapter |
| (all models) |
49Y4202 |
| . |
Emulex 10 Gb Ethernet Integrated Virtual Fabric Adapter II |
| (Models D1x, D2x, F1x, F2x, H1x, H2x, H3x, H7Y) |
49Y7942 |
| . |
Cable management arm |
| (all models) |
49Y4817 |
| . |
Cables |
| ServeRAID M5100 Series 425mm Flash Power Module |
90Y7310 |
| Operator panel (all models) |
69Y2276 |
| Power or configuration (4-drive backplane) |
69Y2278 |
| (models A2x A3x, A5x, A6x, A7x, C1x, F1x, F2x, 1Rx, 2Rx, 3Gx 3Rx, 4Rx, 3Sx, 4Sx, 2Dx, 3Dx, 3Fx, 3Jx, 4RX) |
| Power or configuration (8-drive backplane) |
69Y2279 |
| Y-power |
39M5523 |
| Power (solid state drives) (all models) |
69Y2289 |
| Cable kit, SAS signal, 820 mm and 950 mm (all models) |
69Y2281 |
| DVD and Simple-Swap SATA signal or power assembly (all models) |
90Y7299 |
| Video power (models AC1, AC3, AC4, CTO, MCI) |
69Y2283 |
| USB or video (all models) |
69Y2277 |
| Power (power interposer card) |
69Y2280 |
| (models 2Dx, 3Dx, 3Fx, 3Jx, D1x, D2x, F1x, F2x) |
| QPI 2U or 2U |
69Y2287 |
| QPI 2U or 1U (models 2Dx, 3Sx, 4Sx, F1x, F2x) |
40K6751 |
| . |
Cords |
| Y-jumper power |
39M5523 |
| 2.8m line cord (models A1x, A2x, A3x, A5x, A6x, A7x, C1x, D1x, D2x, F1x, F2x, A1X, 1Rx, 2Rx, 3Rx, 3Gx, 4Rx, ARx, 3Sx, 4Sx, 3Dx, 3Fx, 3Jx, 2Dx, 4Rx) |
39M5377 |
| . |
Fillers |
| QPI ports (all models except 2Dx, 3Sx, and 4Sx) |
69Y2290 |
| DVD drive bay (all models) |
49Y4868 |
| SATA drive bay |
49Y5360 |
| PCI riser slot (models ARx, A1x, A1X) |
69Y2292 |
| Power supply bay (all models) |
49Y4821 |
| . |
Slide lock-out disabler |
| |
(2-node) |
69Y2301 |
| . |
Labels |
| |
System service (all models) |
69Y2299 |
| . |
Label kit |
| |
(machine types 7147 and 7192) |
88Y5762 |
| . |
Miscellaneous parts kit |
| |
(all models) |
69Y2300 |
| . |
ServeRAID |
| |
ServeRAID M5015 SAS or SATA adapter battery carrier kit |
(69Y2300) |
| (this part is included in part number 69Y2300) |
| |
ServeRAID M5016 SAS or SATA adapter (7147, 7192) |
90Y4304 |
| |
ServeRAID M5015 SAS or SATA adapter |
46M0851 |
| |
ServeRAID M1015 SAS or SATA adapter |
46M0861 |
| |
ServeRAID B5015 Solid State Drive adapter |
46M0970 |
| (models AC1, AC3, AC4, CTO, MC1, A1x, D1x, D2x, A1X) |
| . |
Host Bus Adapter |
| |
6 GB Solid State Drive Host Bus Adapter |
46M0913 |
| (models AC1, AC3, AC4, CTO, MC1) |
| . |
ServeRAID Expansion adapter |
| |
4x4 Drive Backplane ServeRAID Expansion adapter |
46M0997 |
| . |
Rack latch kit |
| |
2U (all models) |
69Y2295 |
| . |
Slide rail kit |
| |
(all models) |
60Y0328 |
| . |
Thermal grease kit |
| |
(All models) |
41Y9292 |
| . |
Hypervisor |
| |
Embedded USB flash device |
42D0545 |
| . |
Battery |
| |
3.0 volt |
15F8409 |
| . |
Alcohol wipe |
| |
Canada |
41Y8746 |
| |
Brazil or Mexico |
41Y8747 |
| |
Taiwan or Japan |
41Y8748 |
| |
China or Malaysia |
41Y8749 |
| |
Australia or UK |
41Y8750 |
| |
Korea |
41Y8751 |
| |
Hungary |
41Y8753 |
| |
Latin America |
41Y8754 |
| |
China |
41Y8757 |
| |
Hong Kong |
41Y8758 |
| |
India |
41Y8759 |
| |
Singapore |
41Y8760 |
| |
other countries |
41Y8752 |
