| 1 |
Power backplane |
| (all models) |
43W8673 |
| 2 |
Fan |
| 92 mm (all models) |
43W9578 |
| 3 |
Fan |
| 120 mm (all models) |
44E4563 |
| 4 |
Fan cage |
| (all models) |
44E4576 |
| 5 |
Memory-card guide |
| (all models) |
44E4575 |
| 6 |
Microprocessor |
| Dual-Core 2.4 GHz |
44E4558 |
| Quad-Core 2.13 GHz |
44E4557 |
| Quad-Core 2.4 GHz |
44E4556 |
| Quad-Core 2.93 GHz |
44E4555 |
| 7 |
Microprocessor board |
| (all models) |
43W8670 |
| 8 |
SAS hard drive backplane |
| 92 mm (all models) |
44W2728 |
| 9 |
Media-hood |
| (all models) |
44E4574 |
| 10 |
Chassis |
| (all models) |
44E4573 |
| 11 |
EIA mounting bracket (right and left) |
| (all models) |
44E4570 |
| 12 |
Bezel |
| (all models) |
44E4564 |
| 13 |
Operator information panel |
| (all models) |
44E4372 |
| 14 |
Hard drive |
| 73 GB 15000 rpm(optional) |
43X0839 |
| 73 GB 10000 rpm(optional) |
39R7366 |
| 146 GB 10000 rpm (optional) |
43X0825 |
| 15 |
Hard disk drive filler |
| (all models) |
26K8680 |
| 16 |
CD-RW/DVD-ROM drive |
| CD-RW/DVD-ROM drive (primary) (all models) |
43W4603 |
| DVD-ROM (all models) |
43W4605 |
| DVD-RW (all models) |
43W4607 |
| DVD-RW (all models) |
43W4609 |
| Ultra slim DVD-ROM (all models) |
43W4619 |
| 17 |
DVD housing with interposer card |
| (all models) |
44E4552 |
| 18 |
Microprocessor VRM |
| (all models) |
44E4553 |
| 19 |
Memory card |
| (all models) |
43W8672 |
| 20 |
Memory |
| 1 GB PC2-5300 ECC (all models) |
41Y2761 |
| 2 GB PC2-5300 ECC (optional) |
41Y2770 |
| 4 GB PC2-5300 ECC (optional) |
41Y2851 |
| 8 GB PC2-5300 ECC (optional) |
43V7355 |
| 21 |
Heat sink |
| (all models) |
43W9559 |
| 22 |
Top cover |
| (all models) |
43E4572 |
| 23 |
PCI switch-card |
| (all models) |
44E4373 |
| 24 |
I/O board shuttle |
| (all models) |
43W8671 |
| 25 |
Power supply |
| 1440 W (all models) |
39Y7355 |
| 26 |
ServeRAID-MR10k controller |
| (all models) optional |
43W4282 |
| . |
Alcohol wipes |
| Canada |
41Y8746 |
| Brazil/Mexico |
41Y8747 |
| Taiwan/Japan |
41Y8748 |
| China/Malaysia |
41Y8749 |
| Australia/UK |
41Y8750 |
| Korea |
41Y8751 |
| Hungary |
41Y8753 |
| Latin America |
41Y8754 |
| China |
41Y8757 |
| Hong Kong |
41Y8758 |
| India |
41Y8759 |
| Singapore |
41Y8760 |
| Other countries |
41Y8752 |
| . |
3.0 volt battery |
| (all models) |
15F8409 |
| . |
Cable kit |
| (all models) contents: |
44E4568 |
| |
| Remote Supervisor Adapter II to I/O board 200 mm (7.9 inch) |
| SAS power to I/O board 475 mm (18.7 inch) |
| Hot-swap PCI switch to I/O board 150 mm (5.9 inch) |
| Dual USB ports to I/O board 595 mm (23.4 inch) |
| Media interposer card to I/O board 475 mm (18.7 inch) |
| SAS 4x signal to I/O board 475 mm (18.7 inch) |
| Front panel/light path diagnostics to I/O board 565 mm (22.2 inch) |
| |
| . |
Cable management arm kit |
| (all models) |
40K6556 |
| . |
DVD/CD-ROM bay filler |
| (all models) |
44E4585 |
| . |
Internal flash memory |
| (all models) |
44E4380 |
| . |
Line cord |
| (all models) |
39M5377 |
| . |
Miscellaneous hardware parts |
| (all models) contents: |
44E4587 |
| |
| M6 screws for slide rails (4x) |
| RSA II knob |
| left and right shipping brackets |
| |
| . |
Miscellaneous plastic parts |
| (all models) contents: |
44W4321 |
| |
|
| SAS backplane handle |
|
| VRM handle |
|
| heat sink filler |
|
| PCI divider (2x) |
|
| PCI divider with RAID controller battery holder |
|
| PCI retention bracket |
|
| media hoodair baffle (2x) |
|
| memory bulkhead sliders (2x) |
|
| rear I/O shuttle handle and associated screws |
|
| cable strain relief brackets |
|
| M3.5 screws for PCI adapters (2x) |
|
| |
|
| . |
Rear I/O shuttle |
| (all models) |
44E4582 |
| . |
Remote Supervisor Adapter II |
| (all models) |
13N0832 |
| . |
ServeRAID-MR10k battery pack |
| (all models) optional |
43W4283 |
| . |
Slide kit |
| (all models) |
42D3062 |
| . |
Label kit |
| (all models) contents: |
44E4567 |
| |
| I/O board/RSA II label |
| system service label |
| FRU list label |
| memory card label |
